Material: | Aluminum Alloy | Temper: | T5 |
---|---|---|---|
Alloy: | 6063 / 6061 / 6060 | Surface: | Powder Painted |
Standard: | GB/75237-2004, Q/320281/PDWD-2008 | ||
Highlight: | extruded aluminium profiles,profile aluminum extrusions |
We are the professional manufacturer for good quality competitive price
Hentec Industry Co.,Ltd focus on design, producing and manufacturing aluminium extrusion, extrude aluminum profiles, aluminium tube, aluminum window door and curtain wall profiles and PV solar module aluminum frame for solar panel with the largest extruder as 4000 tonnage. We produce more than 100, 000 tons aluminum products annually.
Top Quality Decorat Aluminium Window Extrusion Profiles / With Competitive Price
Type Option: Sliding, Casement, Fixed, Arch, Tilt & Turn, Awning, Folding, Louver, Circle and etc
Color: As your request
Size: As your request
Frame Material: China brand Aluminum profile with more than 1.4mm thickness for window and 2.0mm thickness for door
Aluminum Option: Normal aluminum profile, Thermal-Break aluminum profile
Glass Option: Clear glass, Laminated glass, Tinted glass, Low-E glass, Frosted glass, all tempered glass
Single layer glass: 4mm, 5mm, 6mm, 8mm, 10mm, 12mm and etc
Double layer glass: 5+9A+5mm, 5+12A+5mm, 6+12A+6mm and etc
Triple glass: 6+9A+6+9A+6mm and etc
Opening Method: Inwards or Outwards, right or left hand opening as your request
Mosquito Screen: Metal and Nylon material for option
Roller shutter: Optional
Surface Treatment: Powder coating, anodizing, electrophoresis coating
Applications
Used in casement doors and windows for living room, dinner room, bathroom, office room, meeting room, restaurant, hotel,etc.
Specifications:
1.Primary Technical Data
1)Chemical composition
Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Zn |
Ti |
Impurity |
Al |
6063 |
0.2-0.6 |
0.35 |
0.1 |
0.1 |
0.45-0.9 |
0.1 |
0.1 |
0.1 |
0.15 |
Rest |
6061 |
0.4-0.8 |
0.7 |
0.15-0.4 |
0.15 |
0.8-1.2 |
0.04-0.35 |
0.25 |
0.15 |
0.15 |
Rest |
6060 |
0.3-0.6 |
0.1-0.3 |
0.1 |
0.1 |
0.35-0.6 |
- |
0.15 |
0.1 |
0.15 |
Rest |
6005 |
0.6-0.9 |
0.35 |
0.1 |
0.1 |
0.40-0.6 |
0.1 |
0.1 |
0.1 |
0.15 |
Rest |
2)Mechanical property
Alloy |
Temper |
Tensile strength |
Yield strength |
Elongation |
6063 |
T5 |
≥ 160Mpa |
≥ 110Mpa |
≥ 8% |
T6 |
≥ 205Mpa |
≥ 180Mpa |
≥ 8% |
|
6061 |
T6 |
≥ 265Mpa |
≥ 245Mpa |
≥ 8% |
Drawing :
Competitive Advantage:
1)Engineering design and support.
2)Aluminium profiles deeply processing:cutting,punching,drilling,milling,and fabricating.
3)High Quality system, strictly inspection during production and whole inspection before package.
4)Good performance, product warranty for 15 years.
