Product Details:
Payment & Shipping Terms:
|
| Product Name: | Aluminium Heatsink Extrusion Profiles | Alloy: | 6063,6061,6005 |
|---|---|---|---|
| Material: | Aluminum | Suface Treatment: | Mill Finished, Anodized |
| Deep Process: | Milling, Drilling, Bending,Cutting | Temper: | T4, T5, T6 ,T66 |
| Highlight: | heatsink extrusion profiles,aluminium heatsink extrusion |
||
Descrition:
Hentec Industry is dedicated to the development, manufacture and marketing of high-performance aluminum extrusion profiles . We pride ourselves on rapid sampling, flexible production methodologies and world-class technical support to our customers. We have significant experience in the thermal management arena and look forward to working with our customers, wherever they are in the world, and however demanding their needs are. And now, our products have been sold in more than 1000 global customers.
Item | Manufacture OEM Aluminum Heatsink Extrusion Profiles , Aluminum Led Heat Sink |
Characteristics of mechanics | 1, Tensile strength: ≥ 205 N/mm2 |
2, Yield strength: ≥ 110 Mpa | |
3, Hardness(HW): ≥ 8 | |
Appearance | 1, No obvious Crack, Scratch , Peeling, Corrosion and air bubble |
2, Hang mark is accepted at two end of the profiles, but should less than 10mm | |
Application | 1, Architecture: Windows and Doors, Curtain Walls, Shutter, Louver, Barrier, Fence, Ceiling, Handrail, balustrades, showcase, Partition |
2, Industrial: tube, pipe, LED strip, heat-sink, motor housing, fins, tent, solar, Vehicle beam, TV Frame | |
3, Furniture: Chair, Wardrobe, Cabinet, Ladder, Closet, Tile Trim | |
Products Feature | 1, Environmentally Friendly, Elegant appearance |
2, Corrosion-Resistant, Abrasion Resistant, High Weather Resistant | |
3, Air-Proof, Water-Proof, Anti-Aging, Durable, Shining |
| Our services | |
| Technology and service | 1. Can carry on the synchronized development design according to the user's needs. |
| 2. Technical consultation | |
| 3. Strictly quality control system | |
| 4. 7days 24 hours on line service | |
| 5. Perfect material purchasing chanels | |
| 6. Look for better way to reduce cost | |
| Software | UG, Catia, ProE, Solidworks, AutoCAD |
| R&D | 15 persons |
| Cooperat with Chongqing university and other professional orgnizations | |
| Management model | Project management |
| Application: | Automobile, Motorcycle, Brake system parts, Transmission parts, Automobile intake system R&D |
Applications:
Aluminum heat sink is widely used on Machines , cars , lighter ...
Specifications:
1. Primary Technical Data
1)Chemical composition
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rest |
6060 | 0.3-0.6 | 0.1-0.3 | 0.1 | 0.1 | 0.35-0.6 | - | 0.15 | 0.1 | 0.15 | Rest |
6005 | 0.6-0.9 | 0.35 | 0.1 | 0.1 | 0.40-0.6 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
2) Mechanical property
Alloy | Temper | Tensile strength | Yield strength | Elongation |
6063 | T5 | ≥ 160Mpa | ≥ 110Mpa | ≥ 8% |
T6 | ≥ 205Mpa | ≥ 180Mpa | ≥ 8% | |
6061 | T6 | ≥ 265Mpa | ≥ 245Mpa | ≥ 8% |
Competitive Advantage:
We can offer professional Manufacturing and exporting service, OEM/ODM for Metal & Plastic parts in China. All the parts manufactured by CNC Lathe & Milling Machine Center.
